- 6R4 Type Dry Sump Tank Split With Integrated Catch Tank Black Anodised
- Stock: In Stock
- Model: GRP4317B
- Weight: 3.24kg
- JAN: M1
Available Options
Introducing our top-tier Dry Sump Tank with integrated catch tank Black Anodised.
This easy-to-clean Dry Sump Tank features a billet-machined flange, secured with 12 x M6 bolts and a re-useable Rubber O ring.
This unique design ensures quick and hassle-free cleaning and oil changing, and also allows the Top of the Tank to be repositioned or turned to another direction.
Our Dry Sump Tank is specially engineered for maximum oil de-aeration. It includes an anti-surge outlet to provide ultimate engine protection.
The tank has inlet and outlet fittings with 5/8" BSP threads.
The tank also features a 5/8" BSP breather outlet. We offer adaptors for Dash 12 and Dash 10, but we recommend maintaining the largest possible size. This is because a larger hose reduces air speed, which in turn minimizes oil siphoning.
The Catch Tank is fitted with 2 off Dash 10 male Fittings.
Customize your tank with our fitting options:
- Blanking Cap Only – This standard fitting comes with every tank.
- Dip Stick Fitted – Replace the standard blanking cap with our dipstick.
- -8 threaded fitting – For additional breathing in engines such as BDA (no dipstick or blanking cap included).
- -10 threaded fitting – For extra breather requirement (no dipstick or blanking cap included).
Tank Specifications:
Height: 415mm.
Diameter: 200mm.
Diameter with Catch Tank 295mm.
Base Plate: 215mm x 215mm.
Maximum capacity: Approximately 7 Litres (up to the internal baffle)
Choose our Dry Sump Tank for optimal engine performance and protection
